Vertical Type Injection Moulding Machine WPM-701-3.5T
Vertical Type Injection Moulding Machine WPM-701-3.5T
  • Vertical Type Injection Moulding Machine WPM-701-3.5T

  • Model No : WPM-701-3.5T
  • Injection Moulding Machine, Plastic Injection Moulding Machine, Vertical Injection Molding Machine
    Screw diWPM-meter (mm) ¢26 / ¢28 / ¢30
    (PS)Max Injection weight (g) 56 / 64 / 74
    (PS)Safe Shot Weight (oz) 2.0 / 2.3/ 2.6
    Screw stroke (mm) 120
    Screw speed rotation (r.p.m.) 0-150
    Nozzle contact force (t f) 2.4
    ClWPM-ping force (tons) 35
    Opening stroke (mm) 200
    Mold space (mm) 570x380
    Min. thickness of mold (mm) 150/100
    Hydraulic ejector force (tons) 1.3
    Injector stroke (mm) 35
    Injection pressure (kg/cm2) 1530 / 1278 / 886
    Oil tank capacity (L) 100
    Drive motor (kW) 6.3
    Dimensions (L x W x H)M 1.5x 1.05x 2.72
    Weight (kg) 1300
  • Inquiry now
Detailed description Vertical Type Injection Moulding Machine WPM-701-3.5T
Injection Moulding Machine, Plastic Injection Moulding Machine, Vertical Injection Molding Machine
Description:
1. WPM-701-3.5T vertical injection molding machine, IS suitable for the common electric appliance plug, the electronic components, and so on small inlays to take shape.

2. Two(three sections)the temperature control/projects the speed/back pressure and so on not to have the section adjustment,701-3.5T Vertical injection molding machine suits components of the precise vertex to take shape.

3. WPM-701-3.5T vertical injection molding machine fast lock mold/low pressure idling speed closes the mold, locks the mold exceptionally when then Automatically tight open the mold. This special safe design, and so on can get up the protective function to the mold.

4. The stop-ping die fixed/op die activity type, takes shape inlays to have a very good localization in the mold. The end product has the fluid capping to leave the installment, the end product takes out extremely facilitates easily.

5. WPM-701-3.5T injection molding machine electrically controlled fitting/hydraulic pressure fitting uses the domestically produced nWPM-e brand The precise durable revolution noise is low. Locks mold strength 15TON - 55TON, has PLC to program- the Electrically controlled computer single to press the control or the computer entire program- the electrically controlled computer single to press the control or the computer entire proportion(ratio presses ratio to flow )controls three kinds, may supply the customer choice.

6. May supplement Sand up mold IS with double slippery mold 2S. It Lets the operator more convenient
Production efficiency Gauguin security.

Specification
Model    WPM-701-3.5T
Screw diWPM-enter (mm)    ¢26 / ¢28 / ¢30
(PS)Max Injection weight (g)    56 / 64 / 74
(PS)Safe Shot Weight (oz)    2.0 / 2.3/ 2.6
Screw stroke (mm)    120
Screw speed rotation (r.p.m.)    0-150
Nozzle contact force (t f)    2.4
ClWPM-ping force (tons)    35
Opening stroke (mm)    200
Mold space (mm)    570x380
Min. thickness of mold (mm)    150/100
Hydraulic ejector force (tons)    1.3
Injector stroke (mm)    35
Injection pressure (kg/cm2)    1530 / 1278 / 886
Oil tank capacity (L)    100
Drive motor (kW)    6.3
Dimensions (L x W x H)M    1.5x 1.05x 2.72
Weight (kg)    1300



If you are interested in this product, please send us your inquiry and we will reply to you ASAP!
