Automatic cable stripping crimping and twisting machine
Features;
This automatic crimping machine is a fully automatic cable processing machine to process wire from cutting,
stripping, crimping, and twisting completely at once. it is suitable for processing all kinds of electric wires from
AWG14#~AWG28#(can be customized), and crimping reel-type terminals like insulated terminals or non-insulated
terminals. the crimping die is made according to your terminals, different terminals can be pressed by this machine
just replace the crimping die, changeover the crimping die is very quick.
Advantages:
1) from feeding cable, cutting, stripping, crimping, and twisting automatically.
2)Available wire range from AWG 14#~AWG 28# with fast speed and accuracy performance.
3)Available for crimping all kinds of chain-type terminals.
4) Changing the crimping die is very quick and convenient within 3 minutes.
5)Can be equipped with a conveyor for processing long wire.
|
Function |
cutting, stripping, crimping, and twisting |
|
Available wire size |
AWG14~AWG28( can be made as your request) |
|
Cutting length |
45mm-9999.9mm |
|
Stripping length |
0-12mm |
|
Cutting accuracy |
0.5mm+cutting length*0.2% |
|
Capacity |
4000-5000pcs/h |
|
Crimping force |
2T |
|
Power supply |
220V 50HZ/60HZ |
|
Air pressure |
0.5-0.7mPa |
