Full Automatic Flat Cable Wire Dividing Cutting  Stripping and Crimpin
Full Automatic Flat Cable Wire Dividing Cutting  Stripping and Crimpin
  • Full Automatic Flat Cable Wire Dividing Cutting Stripping And Crimpin

  • Item No : WPM-FCCM-51

  • Flat Cable Wire Dividing Cutting Stripping And Crimping Machine, Wire Cutting Stripping Crimping Machine, Ferrule Crimping Machine, Stripping And Crimping, Terminal Crimper Machine
    Wire Range: 20P
    Max. Wire Width: 28mm
    Single Wire Width: 0.8-2.5mm
    Cutting Length: 72-9999mm
    Cutting Precision: ±0.5mm
    Stripping Length: 2-10mm
    Crimping Force: 20KN
    Capacity: 18,000PCS/H(20P Flat Wire)
    Power Supply: 220V 50HZ
    Power: 0.75KW
    Air Pressure: 0.4-0.6Mpa
    Weight: 527KGS
    Dimension: 1850*760*1830mm
    Function: Single, Double Ends Crimping, Interval Crimping, Positive And Negative Crimping

Detailed description
Flat Cable Wire Dividing Cutting Stripping and Crimping Machine, Wire Cutting Stripping Crimping Machine, Ferrule Crimping Machine, Stripping And Crimping, Terminal Crimper Machine
1 . Wide applying range: PH, XH, HE, ZH, SCN, SM, VH, Dupont, and other strip connectors and communicating terminals;

2. Good Stability: Eccentric shaft and cam transmission structure, balance crimping force, tide crimping effect, and high rate of finished products;

3. High precision: servo motor driver controls the movement of the flat wire, highly precise terminal crimping control;

4. Crimping mode: steering structure, the crimping direction on the two ends of the wire can be changed;

5. High efficiency: Max, capacity 18,000 PCS/H, 24 hours working;


6. Simple operation: parameters set by touching the screen, the operation is easy to learn, and one worker can operate several machines at the same time:


Wire Range

20P

Max. Wire width

28mm

Single wire width

0.8-2.5mm

Cutting length

72-9999mm

Cutting precision

±0.5mm

Stripping length

2-10mm

Crimping force

20KN

Capacity

18,000PCS/H(20P flat wire)

Power Supply

220V 50HZ

Power

0.75KW

Air pressure

0.4-0.6Mpa

Weight

527KGS

Dimension

1850*760*1830mm

Function

Single, double ends crimping, interval crimping, positive and negative crimping
