Pneumatic wire stripping machine WPM-305
- Model No : WPM-305
- Wire Stripping Machine,Cable Wire Stripping Machines,Cable Peeling Machine
Stripping length 50mm
Wire Dia. 0-5mm
Air Pressure 0.3-0.7mpa
Voltage 220V//50HZ 110V/60HZ
Force 31-73KG
Weight 20KG
Size L400*W300*H270mm - Inquiry now
Wire Stripping Machine, Cable Wire Stripping Machines, Cable Peeling Machine
Pneumatic wire stripping machine (WPM-305)
Function
1. Bevel design, according to somatology.
2. Dual-driving cylinder, no spring breakage.
3. Self-feeding oil and supply. A timely oil supply to the cylinder can decrease the abrasion of the interior cylinder and lengthen life.
4. Special sliding holder, balance stroke, and high peeling precision. Electric control, easy operation.
5. Adjustable structure, and wire thickness.
6. Suitable for short cables with small diameters, such as AC/DC, power wire, computer cable, electronic cable, and multi-core cable.
Model WPM-305
Stripping length 50mm
Wire Dia. 0-5mm
Air Pressure 0.3-0.7mpa
Voltage 220V//50HZ 110V/60HZ
Force 31-73KG
Weight 20KG
Size L400*W300*H270mm
|
Model |
WPM-305 |
WPM-310 |
WPM-315 |
WPM-330 |
WPM-416 |
|
Wire Size |
1 - 5mm |
1 - 10mm |
1 - 15mm |
1 - 20mm |
1 - 30mm |
|
Stripping Length |
3 - 50mm |
3 - 100mm |
3 - 150mm |
3 - 330mm |
3 - 150mm |
|
Cylinder Dia. |
Ø40 |
Ø50 |
Ø60 |
Ø60 |
Ø80 |
|
Force |
31-37Kg |
49-115Kg |
84-196Kg |
84-196Kg |
165-300Kg |
|
Power Supply |
220V |
220V |
220V |
220V |
220V |
|
Dimension |
40×30×27cm |
48×33×28cm |
60×42×36cm |
110×55×45cm |
80×62×55cm |
|
Net. Weight |
20Kg |
25Kg |
35Kg |
65Kg |
50Kg |
|
Packing |
Packed in Wood Case (Standard Export Packing) |
||||
FAQ:
1 Price terms
The price is based on EXW/FOB, if you request CFR or CIF, please give us your delivery port, and we will give you the CFR price or CIF price for reference.
2. What is your main market?
There are kinds of different clients from Asia, Africa, America, and Europe market.
3 . Could provide a professional solution based on our product?
We always promote suitable solutions based on products and satisfy clients with cost-down requirements.
4 Can we provide the sample for testing?
Yes, It will be a pleasure if u provide us with the sample for testing.
5 Do u test all goods before delivery?
Yes,100% test before shipment.
™ products are tested and guaranteed to keep in good quality with one year warranty excluding consumable parts.
If any main parts have quality problems, we will provide new parts and send them to you to change at once with detailed technical support and video illustration, or our experience engineer help to solve them. All problems and questions can be responded to within 24 hours after receiving email/phone/other chatting tools.
