Portable Crimp Analyzer WPM-SES
Portable Crimp Analyzer WPM-SES Portable Crimp Analyzer WPM-SES Portable Crimp Analyzer WPM-SES
  • Portable Crimp Analyzer WPM-SES

  • Model No: WPM-SES

  • The Portable Crimp Analyzer WPM-SES allows for on-the-go crimp quality analysis. This handheld device provides immediate feedback on crimp quality, ensuring consistent and reliable crimped connections in any location.

  • Inquiry now

Detailed description

Cross-section Harness Crimp Cross-section Analysis System
The Crimp Cross-sectional Analysis System is composed of cutting and grinding integrated equipment, optical sampling, corrosion cleaning, cross-section image acquisition system, wire harness terminal picture measurement, and analysis system imported from Japan.
Quick sample making and monitoring can be done with our crimp cross-section analysis system.
The ergonomic design and modular combination make the operation more convenient and fast.
The processing and analysis of one terminal can be completed within 5 minutes, which greatly improves the speed of terminal cross-section quality inspection.
The operation is simple, convenient, and fast. It adopts Japan's high-definition image acquisition system and ensures accurate measurement analysis to protect your production.
High-performance microscopes and special software can measure the length and calculate area simply and correctly.
When observing objects in ultra-high definition, it can generate upright three-dimensional spatial images with strong stereoscopic sense, clear imaging, and clear and wide imaging.
Control System:  Adopt Japanese Mitsubishi PLC controller - SBL
Module cut range:  0.13 ~6.00 mm2
Rotate speed:  2800 rpm (Imported motor from Germany)
Cut speed:  2 mm / sec
Cut wheel inner diameter:  21.7 mm, OD:105 mm, thickness: 0.5 mm (Germany imported, delicate and durable)
Module grind speed:  2800 rpm (Imported motor from Germany)
Z-axis slightly tuning range:  0.00~5.00 mm
Special sandpaper OD:  100 mm
X-axis shift:  Japanese Panasonic servo motor
Eclipse partial electrolysis:  Up to 6 mm2
Electrolysis time:  5~30 sec
Picture ingestion:  High quality, low distortion optical instrument with 10x eyepiece
Amplify multiple:  0.75x, 1x, 1.5x, 2.0x, 2.5x, 3.0x, 3.5x, 4.0x, 4.5x, 5.0x(0.5 stuck position shift technology)
Tooth pitch multiple:  0.75x, 1x, 1.5x, 2.0x, 2.5x, 3.0x, 3.5x, 4.0x, 4.5x, 5.0x(0.5 stuck position shift technology)
Observation range:  1.2~8.2 mm(X-axis direction)
Observation feature 1:  Ultra-bright white LED light source can be controlled infinitely
Observation feature 2:  X Y Z-axis mobile platform with slightly tuning
Range:  +/- 6 mm(Three-dimensional)
Analysis and file record:  Japanese industrial HD video system 3-megapixel camera, USB 2.0, and Section-ms software
Tool certification:
Enhanced measurement tools including compression ratios have been certified in the
automotive/home appliance/IT industry
Voltage and watt:  220VAC, 50Hz, 300W
Weight:  30kg
Dimensions:  490 mm (L) x 340 mm (W) x 340 mm (H)
